参考

安装git

sudo yum install git

docker build -t orchestrator:latest .

docker run -d -p 3000:3000 \
-v /docker/orchestrator/conf.json:/etc/orchestrator.conf.json \
--name orc dzd624175217/orchestrator

下列环境变量可用，并且如果没有配置文件绑定安装到容器中，则以下环境变量生效 /etc/orchestrator.conf.json
ORC_TOPOLOGY_USER：默认为 orchestrator
ORC_TOPOLOGY_PASSWORD：默认为 orchestrator
ORC_DB_HOST：默认为 db
ORC_DB_PORT：默认为 3306
ORC_DB_NAME：默认为 orchestrator
ORC_USER：默认为orc_server_user
ORC_PASSWORD：默认为 orc_server_password
要设置这些变量，可以将它们添加到环境文件中，然后在其中添加它们key=value（每行一对）。然后，您可以将此环境文件传递给docker命令，添加—env-file=path/to/env-file到该docker run命令中

conf.json

{
  "Debug": true,
  "EnableSyslog": false,
  "ListenAddress": ":3000",
  "MySQLTopologyUser": "orc_client_user",
  "MySQLTopologyPassword": "orc_client_password",
  "MySQLTopologyCredentialsConfigFile": "",
  "MySQLTopologySSLPrivateKeyFile": "",
  "MySQLTopologySSLCertFile": "",
  "MySQLTopologySSLCAFile": "",
  "MySQLTopologySSLSkipVerify": true,
  "MySQLTopologyUseMutualTLS": false,
  "BackendDB": "sqlite",
  "SQLite3DataFile": "/usr/local/orchestrator/orchestrator.sqlite3",
  "MySQLConnectTimeoutSeconds": 1,
  "DefaultInstancePort": 3306,
  "DiscoverByShowSlaveHosts": true,
  "InstancePollSeconds": 5,
  "DiscoveryIgnoreReplicaHostnameFilters": [
    "a_host_i_want_to_ignore[.]example[.]com",
    ".*[.]ignore_all_hosts_from_this_domain[.]example[.]com",
    "a_host_with_extra_port_i_want_to_ignore[.]example[.]com:3307"
  ],
  "UnseenInstanceForgetHours": 240,
  "SnapshotTopologiesIntervalHours": 0,
  "InstanceBulkOperationsWaitTimeoutSeconds": 10,
  "HostnameResolveMethod": "default",
  "MySQLHostnameResolveMethod": "@@hostname",
  "SkipBinlogServerUnresolveCheck": true,
  "ExpiryHostnameResolvesMinutes": 60,
  "RejectHostnameResolvePattern": "",
  "ReasonableReplicationLagSeconds": 10,
  "ProblemIgnoreHostnameFilters": [],
  "VerifyReplicationFilters": false,
  "ReasonableMaintenanceReplicationLagSeconds": 20,
  "CandidateInstanceExpireMinutes": 60,
  "AuditLogFile": "",
  "AuditToSyslog": false,
  "RemoveTextFromHostnameDisplay": ".mydomain.com:3306",
  "ReadOnly": false,
  "AuthenticationMethod": "",
  "HTTPAuthUser": "",
  "HTTPAuthPassword": "",
  "AuthUserHeader": "",
  "PowerAuthUsers": [
    "*"
  ],
  "ClusterNameToAlias": {
    "127.0.0.1": "test suite"
  },
  "SlaveLagQuery": "",
  "DetectClusterAliasQuery": "SELECT SUBSTRING_INDEX(@@hostname, '.', 1)",
  "DetectClusterDomainQuery": "",
  "DetectInstanceAliasQuery": "",
  "DetectPromotionRuleQuery": "",
  "DataCenterPattern": "[.]([^.]+)[.][^.]+[.]mydomain[.]com",
  "PhysicalEnvironmentPattern": "[.]([^.]+[.][^.]+)[.]mydomain[.]com",
  "PromotionIgnoreHostnameFilters": [],
  "DetectSemiSyncEnforcedQuery": "",
  "ServeAgentsHttp": false,
  "AgentsServerPort": ":3001",
  "AgentsUseSSL": false,
  "AgentsUseMutualTLS": false,
  "AgentSSLSkipVerify": false,
  "AgentSSLPrivateKeyFile": "",
  "AgentSSLCertFile": "",
  "AgentSSLCAFile": "",
  "AgentSSLValidOUs": [],
  "UseSSL": false,
  "UseMutualTLS": false,
  "SSLSkipVerify": false,
  "SSLPrivateKeyFile": "",
  "SSLCertFile": "",
  "SSLCAFile": "",
  "SSLValidOUs": [],
  "URLPrefix": "",
  "StatusEndpoint": "/api/status",
  "StatusSimpleHealth": true,
  "StatusOUVerify": false,
  "AgentPollMinutes": 60,
  "UnseenAgentForgetHours": 6,
  "StaleSeedFailMinutes": 60,
  "SeedAcceptableBytesDiff": 8192,
  "PseudoGTIDPattern": "",
  "PseudoGTIDPatternIsFixedSubstring": false,
  "PseudoGTIDMonotonicHint": "asc:",
  "DetectPseudoGTIDQuery": "",
  "BinlogEventsChunkSize": 10000,
  "SkipBinlogEventsContaining": [],
  "ReduceReplicationAnalysisCount": true,
  "FailureDetectionPeriodBlockMinutes": 60,
  "RecoveryPeriodBlockSeconds": 3600,
  "RecoveryIgnoreHostnameFilters": [],
  "RecoverMasterClusterFilters": [
    "_master_pattern_"
  ],
  "RecoverIntermediateMasterClusterFilters": [
    "_intermediate_master_pattern_"
  ],
  "OnFailureDetectionProcesses": [
    "echo 'Detected {failureType} on {failureCluster}. Affected replicas: {countSlaves}' >> /tmp/recovery.log"
  ],
  "PreFailoverProcesses": [
    "echo 'Will recover from {failureType} on {failureCluster}' >> /tmp/recovery.log"
  ],
  "PostFailoverProcesses": [
    "echo '(for all types) Recovered from {failureType} on {failureCluster}. Failed: {failedHost}:{failedPort}; Successor: {successorHost}:{successorPort}' >> /tmp/recovery.log"
  ],
  "PostUnsuccessfulFailoverProcesses": [],
  "PostMasterFailoverProcesses": [
    "echo 'Recovered from {failureType} on {failureCluster}. Failed: {failedHost}:{failedPort}; Promoted: {successorHost}:{successorPort}' >> /tmp/recovery.log"
  ],
  "PostIntermediateMasterFailoverProcesses": [
    "echo 'Recovered from {failureType} on {failureCluster}. Failed: {failedHost}:{failedPort}; Successor: {successorHost}:{successorPort}' >> /tmp/recovery.log"
  ],
  "CoMasterRecoveryMustPromoteOtherCoMaster": true,
  "DetachLostSlavesAfterMasterFailover": true,
  "ApplyMySQLPromotionAfterMasterFailover": true,
  "PreventCrossDataCenterMasterFailover": false,
  "PreventCrossRegionMasterFailover": false,
  "MasterFailoverDetachSlaveMasterHost": false,
  "MasterFailoverLostInstancesDowntimeMinutes": 0,
  "PostponeSlaveRecoveryOnLagMinutes": 0,
  "OSCIgnoreHostnameFilters": [],
  "GraphiteAddr": "",
  "GraphitePath": "",
  "GraphiteConvertHostnameDotsToUnderscores": true
}

docker run -d --name orc \
--net orchnet --ip 172.20.0.10 \
-v /home/docker/orc/conf.json:/etc/orchestrator.conf.json \
-p 3000:3000 dzd624175217/orchestrator:latest

for N in 1 2 3
  do docker run -d --name=node$N --hostname=node$N --net orchnet --ip "172.20.0.1$N" \
  -v $PWD/d$N:/var/lib/mysql -e MYSQL_ROOT_PASSWORD=mypass \
  mysql/mysql-server:8.0.15 \
  --server-id=$N \
  --enforce-gtid-consistency='ON' \
  --log-slave-updates='ON' \
  --gtid-mode='ON' \
  --log-bin='mysql-bin-1.log'
done

docker exec -it node1 mysql -uroot -pmypass \
  -e "CREATE USER 'repl'@'%' IDENTIFIED WITH mysql_native_password BY 'slavepass';" \
  -e "GRANT REPLICATION SLAVE ON *.* TO 'repl'@'%';" \
  -e "SHOW MASTER STATUS;"

for N in 2 3
  do docker exec -it node$N mysql -uroot -pmypass \
    -e "CHANGE MASTER TO MASTER_HOST='172.20.0.11', MASTER_PORT=3306, \
        MASTER_USER='repl', MASTER_PASSWORD='slavepass', MASTER_AUTO_POSITION = 1;"
  docker exec -it node$N mysql -uroot -pmypass -e "START SLAVE;"
done

docker exec -it node1 mysql -uroot -pmypass \
  -e "CREATE USER 'orc_client_user'@'172.20.0.10' IDENTIFIED BY 'orc_client_password';" \
  -e "GRANT SUPER, PROCESS, REPLICATION SLAVE, RELOAD ON *.* TO 'orc_client_user'@'172.20.0.10';" \
  -e "GRANT SELECT ON mysql.slave_master_info TO 'orc_client_user'@'172.20.0.10';"
