一、ConcurrentHashMap

1.1 Java7 中的实现

ConcurrentHashMap 采用了分段锁技术，其中 Segment 继承于 ReentrantLock（可重入锁）。不会像 HashTable 那样不管是 put 还是 get 操作都需要做同步处理，理论上 ConcurrentHashMap 支持 CurrencyLevel (Segment 数组数量)的线程并发。每当一个线程占用锁访问一个 Segment 时，不会影响到其他的 Segment。

  • 数据结构图示


  • 成员变量
  1. //定义的常量
  2. //初始时默认容量
  3. static final int DEFAULT_INITIAL_CAPACITY = 16;
  4. //负载因子
  5. static final float DEFAULT_LOAD_FACTOR = 0.75f;
  6. //默认的并发等级，
  7. static final int DEFAULT_CONCURRENCY_LEVEL = 16;
  8. //最大容量
  9.  static final int MAXIMUM_CAPACITY = 1 << 30;
  10. //最小每个Segment持有table数量，必须是2的倍数
  11. static final int MIN_SEGMENT_TABLE_CAPACITY = 2;
  12. //Segment 数组最大容量　65536
  13. static final int MAX_SEGMENTS = 1 << 16;
  14. //不加锁进行检索的数量
  15. static final int RETRIES_BEFORE_LOCK = 2;
  17. //Segment 数组, 数组中的每个元素都持有HashEntry 桶
  18. final Segment<K,V>[] segments;
  20. transient Set<K> keySet;
  21. transient Set<Map.Entry<K,V>> entrySet;
  22. transient Collection<V> values;
  • Segment 的源码实现
  1. static final class Segment<K,V> extends ReentrantLock implements Serializable {
  2.         private static final long serialVersionUID = 2249069246763182397L;
  4.         static final int MAX_SCAN_RETRIES =
  5.             Runtime.getRuntime().availableProcessors() > 1 ? 64 : 1;
  6.         //存放数据的hash 桶
  7.         transient volatile HashEntry<K,V>[] table;
  9.         transient int count;
  11.         transient int modCount;
  13.         transient int threshold;
  15.         final float loadFactor;
  17.         Segment(float lf, int threshold, HashEntry<K,V>[] tab) {
  18.             this.loadFactor = lf;
  19.             this.threshold = threshold;
  20.             this.table = tab;
  21.         }
  22.     }

  • Entry 实现

    1. static final class HashEntry<K,V> {
    2.       final int hash; //hahs值
    3.       final K key;　//键
    4.       volatile V value;　//值
    5.       volatile HashEntry<K,V> next;　　//后继指针
    6. 　    HashEntry(int hash, K key, V value, HashEntry<K,V> next) {
    7.           this.hash = hash;
    8.           this.key = key;
    9.           this.value = value;
    10.           this.next = next;
    11.       }
    12. }

  • 构造函数

    1. public ConcurrentHashMap(int initialCapacity,
    2.                            float loadFactor, int concurrencyLevel) {
    3.       if (!(loadFactor > 0) || initialCapacity < 0 || concurrencyLevel <= 0)
    4.           throw new IllegalArgumentException();
    5.       if (concurrencyLevel > MAX_SEGMENTS)
    6.           concurrencyLevel = MAX_SEGMENTS;
    7.       // Find power-of-two sizes best matching arguments
    8.       int sshift = 0; //sshift等于ssize从1向左移位的次数
    9.       int ssize = 1; //Segment 数组的大小
    10.    //为了能通过按位与的散列算法来定位segments数组的索引,必须保证segments数组的长度是2的N次方
    11. //(power-of-two size),所以必须计算出一个大于或等于concurrencyLevel的最小的2的N次方值
    12. //来作为segments数组的长度。
    13.       while (ssize < concurrencyLevel) {
    14.           ++sshift;
    15.           ssize <<= 1;
    16.       }
    17.    //segmentShift用于定位参与散列运算的位数
    18.       this.segmentShift = 32 - sshift;
    19.    //segmentMask是散列运算的掩码,等于ssize减1,即15,掩码的二进制各个位的值都是1
    20.       this.segmentMask = ssize - 1;
    21.       if (initialCapacity > MAXIMUM_CAPACITY)
    22.           initialCapacity = MAXIMUM_CAPACITY;
    23.       int c = initialCapacity / ssize;
    24.       if (c * ssize < initialCapacity)
    25.           ++c;
    26.       int cap = MIN_SEGMENT_TABLE_CAPACITY;
    27.       while (cap < c)
    28.           cap <<= 1;
    29.       //创建 Segment,并放入Segment数组
    30.       Segment<K,V> s0 =
    31.           new Segment<K,V>(loadFactor, (int)(cap * loadFactor),
    32.                            (HashEntry<K,V>[])new HashEntry[cap]);
    33.       Segment<K,V>[] ss = (Segment<K,V>[])new Segment[ssize];
    34.       UNSAFE.putOrderedObject(ss, SBASE, s0); // ordered write of segments[0]
    35.       this.segments = ss;
    36.   }

  • get 方法

    1. public V get(Object key) {
    2.       Segment<K,V> s; // manually integrate access methods to reduce overhead
    3.       HashEntry<K,V>[] tab;
    4.       //对key 进行散列，得到hash值
    5.       int h = hash(key);
    6.       //计算出key 所在的segments数组下标
    7.       long u = (((h >>> segmentShift) & segmentMask) << SSHIFT) + SBASE;
    8.       if ((s = (Segment<K,V>)UNSAFE.getObjectVolatile(segments, u)) != null &&
    9.           (tab = s.table) != null) {
    10.           //遍历桶中的元素，找到key对应的的元素
    11.           for (HashEntry<K,V> e = (HashEntry<K,V>) UNSAFE.getObjectVolatile
    12.                    (tab, ((long)(((tab.length - 1) & h)) << TSHIFT) + TBASE);
    13.                e != null; e = e.next) {
    14.               K k;
    15.               if ((k = e.key) == key || (e.hash == h && key.equals(k)))
    16.                   return e.value;
    17.           }
    18.       }
    19.       return null;
    20.   }

get操作的高效之处在于整个get过程不需要加锁

  • put 方法了解
  1. public V put(K key, V value) {
  2.         Segment<K,V> s;
  3.         if (value == null)
  4.             throw new NullPointerException();
  5.         //对key 进行散列
  6.         int hash = hash(key);
  7.         //计算存放到哪个Segment
  8.         int j = (hash >>> segmentShift) & segmentMask;
  9.         if ((s = (Segment<K,V>)UNSAFE.getObject          // nonvolatile; recheck
  10.              (segments, (j << SSHIFT) + SBASE)) == null) //  in ensureSegment
  11.             s = ensureSegment(j);
  12.         return s.put(key, hash, value, false);
  13.     }
  1. //如果不存在，创建Segment,并返回
  2. private Segment<K,V> ensureSegment(int k) {
  3.         final Segment<K,V>[] ss = this.segments;
  4.         long u = (k << SSHIFT) + SBASE; // raw offset
  5.         Segment<K,V> seg;
  6.         if ((seg = (Segment<K,V>)UNSAFE.getObjectVolatile(ss, u)) == null) {
  7.             Segment<K,V> proto = ss[0]; // use segment 0 as prototype
  8.             int cap = proto.table.length;
  9.             float lf = proto.loadFactor;
  10.             int threshold = (int)(cap * lf);
  11.             HashEntry<K,V>[] tab = (HashEntry<K,V>[])new HashEntry[cap];
  12.             if ((seg = (Segment<K,V>)UNSAFE.getObjectVolatile(ss, u))
  13.                 == null) { // recheck
  14.                 Segment<K,V> s = new Segment<K,V>(lf, threshold, tab);
  15.                 while ((seg = (Segment<K,V>)UNSAFE.getObjectVolatile(ss, u))
  16.                        == null) {
  17.                     if (UNSAFE.compareAndSwapObject(ss, u, null, seg = s))
  18.                         break;
  19.                 }
  20.             }
  21.         }
  22.         return seg;
  23.     }

找到对应的Segment，执行put 方法

  1. final V put(K key, int hash, V value, boolean onlyIfAbsent) {
  2.             HashEntry<K,V> node = tryLock() ? null : //1
  3.                 scanAndLockForPut(key, hash, value); //2
  4.             V oldValue;
  5.             try {
  6.                 HashEntry<K,V>[] tab = table;
  7.                 int index = (tab.length - 1) & hash;
  8.                 HashEntry<K,V> first = entryAt(tab, index); //3
  9.                 for (HashEntry<K,V> e = first;;) {
  10.                     if (e != null) {
  11.                         K k;
  12.                         if ((k = e.key) == key ||
  13.                             (e.hash == hash && key.equals(k))) {//4
  14.                             oldValue = e.value;
  15.                             if (!onlyIfAbsent) {
  16.                                 e.value = value;
  17.                                 ++modCount;
  18.                             }
  19.                             break;
  20.                         }
  21.                         e = e.next;
  22.                     }
  23.                     else {//5
  24.                         if (node != null)
  25.                             node.setNext(first);
  26.                         else
  27.                             node = new HashEntry<K,V>(hash, key, value, first);
  28.                         int c = count + 1;
  29.                         if (c > threshold && tab.length < MAXIMUM_CAPACITY)
  30.                             rehash(node);
  31.                         else
  32.                             setEntryAt(tab, index, node);
  33.                         ++modCount;
  34.                         count = c;
  35.                         oldValue = null;
  36.                         break;
  37.                     }
  38.                 }
  39.             } finally {
  40.                 unlock(); //6
  41.             }
  42.             return oldValue;
  43.         }
  1. 首先第一步的时候会尝试获取锁: tryLock()
  2. 如果获取失败肯定就有其他线程存在竞争，则利用 scanAndLockForPut() 自旋获取锁。
  3. 将当前 Segment 中的 table 通过 key 的 hashcode 定位到 HashEntry。
  4. 遍历该 HashEntry，如果不为空则判断传入的 key 和当前遍历的 key 是否相等，相等则覆盖旧的 value。
  5. 不为空则需要新建一个 HashEntry 并加入到 Segment 中，同时会先判断是否需要扩容。
  6. 最后会解除在 1 中所获取当前 Segment 的锁。
  • scanAndLockForPut方法
    1.  private HashEntry<K,V> scanAndLockForPut(K key, int hash, V value) {
    2.           HashEntry<K,V> first = entryForHash(this, hash);
    3.           HashEntry<K,V> e = first;
    4.           HashEntry<K,V> node = null;
    5.           int retries = -1; // negative while locating node
    6.           while (!tryLock()) { //1
    7.               HashEntry<K,V> f; // to recheck first below
    8.               if (retries < 0) {
    9.                   if (e == null) {
    10.                       if (node == null) // speculatively create node
    11.                           node = new HashEntry<K,V>(hash, key, value, null);
    12.                       retries = 0;
    13.                   }
    14.                   else if (key.equals(e.key))
    15.                       retries = 0;
    16.                   else
    17.                       e = e.next;
    18.               }
    19.               else if (++retries > MAX_SCAN_RETRIES) {//2
    20.                   lock();
    21.                   break;
    22.               }
    23.               else if ((retries & 1) == 0 &&
    24.                        (f = entryForHash(this, hash)) != first) {
    25.                   e = first = f; // re-traverse if entry changed
    26.                   retries = -1;
    27.               }
    28.           }
    29.           return node;
    30.       }
  1. 尝试自旋获取锁。
  2. 如果重试的次数达到了 MAX_SCAN_RETRIES 则改为阻塞锁获取，保证能获取成功。
  • rehash方法
  1. private void rehash(HashEntry<K,V> node) {
  3.             HashEntry<K,V>[] oldTable = table;
  4.             int oldCapacity = oldTable.length;
  5.             int newCapacity = oldCapacity << 1;　//1
  6.             threshold = (int)(newCapacity * loadFactor);
  7.             HashEntry<K,V>[] newTable =
  8.                 (HashEntry<K,V>[]) new HashEntry[newCapacity];
  9.             int sizeMask = newCapacity - 1;
  10.             for (int i = 0; i < oldCapacity ; i++) {
  11.                 HashEntry<K,V> e = oldTable[i];
  12.                 if (e != null) {
  13.                     HashEntry<K,V> next = e.next;
  14.                     int idx = e.hash & sizeMask;
  15.                     if (next == null)   //  Single node on list  //2
  16.                         newTable[idx] = e;
  17.                     else { // Reuse consecutive sequence at same slot //3
  18.                         HashEntry<K,V> lastRun = e;
  19.                         int lastIdx = idx;
  20.                         for (HashEntry<K,V> last = next;
  21.                              last != null;
  22.                              last = last.next) {
  23.                             int k = last.hash & sizeMask;
  24.                             if (k != lastIdx) {
  25.                                 lastIdx = k;
  26.                                 lastRun = last;
  27.                             }
  28.                         }
  29.                         newTable[lastIdx] = lastRun;
  30.                         // Clone remaining nodes
  31.                         for (HashEntry<K,V> p = e; p != lastRun; p = p.next) {
  32.                             V v = p.value;
  33.                             int h = p.hash;
  34.                             int k = h & sizeMask;
  35.                             HashEntry<K,V> n = newTable[k];
  36.                             newTable[k] = new HashEntry<K,V>(h, p.key, v, n);
  37.                         }
  38.                     }
  39.                 }
  40.             }
  41.             int nodeIndex = node.hash & sizeMask; // add the new node
  42.             node.setNext(newTable[nodeIndex]);
  43.             newTable[nodeIndex] = node;
  44.             table = newTable;
  45.         }
  1. 计算新的容量为旧容量的2倍
  2. 遍历旧HashEntry桶，如果当前HashEntry只用一个节点，直接放到新的HashEntry桶中
  3. 如果当前HashEntry是链表，则遍历链表，重新计算下标放到新的HashEntry桶中

1.2 Java8 中的实现

  • 数据结构图示

抛弃了原有的 Segment 分段锁，而采用了 CAS + synchronized 来保证并发安全性。结构上也引入了红黑树，防止查询效率退化为O(N)

  • Node类与Java7　HashEntry类似

    1. static class Node<K,V> implements Map.Entry<K,V> {
    2.       final int hash;
    3.       final K key;
    4.       volatile V val;　//volatile保证可见性
    5.       volatile Node<K,V> next;
    7.       Node(int hash, K key, V val, Node<K,V> next) {
    8.           this.hash = hash;
    9.           this.key = key;
    10.           this.val = val;
    11.           this.next = next;
    12.       }
    13. }

  • get方法

  1.  public V get(Object key) {
  3.         Node<K,V>[] tab; Node<K,V> e, p; int n, eh; K ek;
  4.         int h = spread(key.hashCode());
  5.         if ((tab = table) != null && (n = tab.length) > 0 &&
  6.             (e = tabAt(tab, (n - 1) & h)) != null) {
  7.              //根据计算出来的 hashcode 寻址，如果就在桶上那么直接返回值。
  8.             if ((eh = e.hash) == h) {
  9.                 if ((ek = e.key) == key || (ek != null && key.equals(ek)))
  10.                     return e.val;
  11.             }
  12.             else if (eh < 0)//如果是红黑树那就按照树的方式获取值。
  13.                 return (p = e.find(h, key)) != null ? p.val : null;
  14.             while ((e = e.next) != null) { 就不满足那就按照链表的方式遍历获取值。
  15.                 if (e.hash == h &&
  16.                     ((ek = e.key) == key || (ek != null && key.equals(ek))))
  17.                     return e.val;
  18.             }
  19.         }
  20.         return null;
  21.     }
  • put 方法
    1. final V putVal(K key, V value, boolean onlyIfAbsent) {
    2.       if (key == null || value == null) throw new NullPointerException();
    3.       int hash = spread(key.hashCode());
    4.       int binCount = 0;
    5.       for (Node<K,V>[] tab = table;;) {
    6.           Node<K,V> f; int n, i, fh;
    7.           //如果桶为空，初始化
    8.           if (tab == null || (n = tab.length) == 0)
    9.               tab = initTable();
    10.           else if ((f = tabAt(tab, i = (n - 1) & hash)) == null) {
    11.               //采用CAS无锁put入新的元素，成功返回
    12.               //失败自旋
    13.               if (casTabAt(tab, i, null,
    14.                            new Node<K,V>(hash, key, value, null)))
    15.                   break;                   // no lock when adding to empty bin
    16.           }
    17.           //如果当前位置的 hashcode == MOVED == -1,则需要进行扩容。
    18.           else if ((fh = f.hash) == MOVED)
    19.               tab = helpTransfer(tab, f);
    20.           else {
    21.               //如果都不满足，则利用 synchronized 锁写入数据。
    22.               V oldVal = null;
    23.               synchronized (f) {
    24.                   if (tabAt(tab, i) == f) {
    25.                       if (fh >= 0) {
    26.                           binCount = 1;
    27.                           for (Node<K,V> e = f;; ++binCount) {
    28.                               K ek;
    29.                               if (e.hash == hash &&
    30.                                   ((ek = e.key) == key ||
    31.                                    (ek != null && key.equals(ek)))) {
    32.                                   oldVal = e.val;
    33.                                   if (!onlyIfAbsent)
    34.                                       e.val = value;
    35.                                   break;
    36.                               }
    37.                               Node<K,V> pred = e;
    38.                               if ((e = e.next) == null) {
    39.                                   pred.next = new Node<K,V>(hash, key,
    40.                                                             value, null);
    41.                                   break;
    42.                               }
    43.                           }
    44.                       }
    45.                       else if (f instanceof TreeBin) {
    46.                           Node<K,V> p;
    47.                           binCount = 2;
    48.                           if ((p = ((TreeBin<K,V>)f).putTreeVal(hash, key,
    49.                                                          value)) != null) {
    50.                               oldVal = p.val;
    51.                               if (!onlyIfAbsent)
    52.                                   p.val = value;
    53.                           }
    54.                       }
    55.                   }
    56.               }
    57.               if (binCount != 0) {
    58.                   //如果达到需要转换为红黑树的阀值 TREEIFY_THRESHOLD = 8
    59.                   if (binCount >= TREEIFY_THRESHOLD)
    60.                       treeifyBin(tab, i);//将链表转换为红黑树
    61.                   if (oldVal != null)
    62.                       return oldVal;
    63.                   break;
    64.               }
    65.           }
    66.       }
    67.       addCount(1L, binCount);
    68.       return null;
    69.   }

二、 CopyOnWriteArrayList

基于Java8 了解源码实现
原理: 采用读写分离的思想实现并发访问, 而且保证读读之间在任何时候都不会被阻塞。
缺点:

  • 内存占用问题
  • 数据一致性问题

适合场景： 用于读多写少的并发场景

2.1 内部成员

  1. //可重入锁
  2. final transient ReentrantLock lock = new ReentrantLock();
  4. //数组　volatile:保证可见性，　
  5. private transient volatile Object[] array;
  7. //弱一致性的迭代器
  8. static final class COWIterator<E> implements ListIterator<E>
  10. // 反射机制 Unsafe类
  11. private static final sun.misc.Unsafe UNSAFE;
  12. // lock域的内存偏移量
  13. private static final long lockOffset;
  14. static {
  15.     try {
  16.         //实例化Unsafe类
  17.         UNSAFE = sun.misc.Unsafe.getUnsafe();
  18.         Class<?> k = CopyOnWriteArrayList.class;
  19.         //锁的偏移量
  20.         lockOffset = UNSAFE.objectFieldOffset
  21.             (k.getDeclaredField("lock"));
  22.     } catch (Exception e) {
  23.         throw new Error(e);
  24.     }
  25. }

2.2　构造方法

  1. public CopyOnWriteArrayList() {
  2.         setArray(new Object[0]); //初始化长度为0 的数组
  3. }
  5. public CopyOnWriteArrayList(Collection<? extends E> c) {
  6.     Object[] elements;
  7.     if (c.getClass() == CopyOnWriteArrayList.class)
  8.         elements = ((CopyOnWriteArrayList<?>)c).getArray();
  9.     else {
  10.         elements = c.toArray();
  11.         // c.toArray might (incorrectly) not return Object[] (see 6260652)
  12.         if (elements.getClass() != Object[].class)
  13.             elements = Arrays.copyOf(elements, elements.length, Object[].class);
  14.     }
  15.     setArray(elements);
  16. }
  18. public CopyOnWriteArrayList(E[] toCopyIn) {
  19.     setArray(Arrays.copyOf(toCopyIn, toCopyIn.length, Object[].class));
  20. }

2.3 get方法

  1. //volatile 修饰数组引用，保证可见性
  2. private transient volatile Object[] array;
  4. final Object[] getArray() {
  5.     return array;
  6. }
  8. public E get(int index) {
  9.     return get(getArray(), index);
  10. }
  13. @SuppressWarnings("unchecked")
  14. private E get(Object[] a, int index) {
  15.     return (E) a[index]; //通过下标获取数组元素， 没有做任何加锁操作
  16. }

2.4 add 方法

  1. public boolean add(E e) {
  2.     final ReentrantLock lock = this.lock;
  3.     lock.lock(); //获取锁
  4.     try {
  5.         //获取原数组
  6.         Object[] elements = getArray();
  7.         int len = elements.length;
  8.         //拷贝原数组到新的新数组
  9.         Object[] newElements = Arrays.copyOf(elements, len + 1);
  10.         //操作新的数组
  11.         newElements[len] = e;
  12.         //将旧数组引用指向新的数组
  13.         setArray(newElements);
  14.         return true;
  15.     } finally {
  16.         lock.unlock(); //释放锁
  17.     }
  18. }

三、阻塞队列BlockingQueue

原理：采用等待通知机制实现， 底层采用可重入锁和Condition实现

3.1 JDK 中的阻塞队列实现

  • ArrayBlockingQueue 一个由数组结构组成的有界阻塞队列。
  • LinkedBlockingQueue 一个由链表结构组成的有界阻塞队列。
  • PriorityBlockingQueue 一个支持优先级排序的无界优先级阻塞队列。
  • DelayQueue:一个使用优先级队列实现的无界延迟阻塞队列。
  • SynchronousQueue 一个不存储元素的阻塞队列。
  • LinkedTransferQueue 一个由链表结构组成的无界阻塞队列。
  • LinkedBlockingDeque 一个由链表结构组成的双向阻塞队列。

3.2 对ArrayBlockingQueue 进行分析(Java8)

3.2.1 成员变量
  1. //队列容器数组
  2. final Object[] items;
  4. /** items index for next take, poll, peek or remove */
  5. int takeIndex;
  7. /** items index for next put, offer, or add */
  8. int putIndex;
  10. //队列元素个数
  11. int count;
  13. //可重入锁
  14. final ReentrantLock lock;
  16. //队列条件锁（队列挂起出队列线程）
  17. private final Condition notEmpty;
  19. //队列条件锁（队列挂起入队列线程）
  20. private final Condition notFull;

3.2.2 构造函数
  1. //capacity 容量
  2. //fair 是否公平访问队列：()
  3. //true 在插入和删除操作中会阻塞线程，按照FIFO的顺序执行访问，
  4. //false 线程访问顺序不确定
  5. public ArrayBlockingQueue(int capacity, boolean fair) {
  6.     if (capacity <= 0)
  7.         throw new IllegalArgumentException();
  8.     this.items = new Object[capacity];
  9.     lock = new ReentrantLock(fair);
  10.     notEmpty = lock.newCondition();
  11.     notFull =  lock.newCondition();
  12. }
  15. public ArrayBlockingQueue(int capacity, boolean fair,
  16.                           Collection<? extends E> c) {
  17.     this(capacity, fair);
  19.     final ReentrantLock lock = this.lock;
  20.     lock.lock(); // Lock only for visibility, not mutual exclusion
  21.     try {
  22.         int i = 0;
  23.         try {
  24.             for (E e : c) {
  25.                 checkNotNull(e);
  26.                 items[i++] = e;
  27.             }
  28.         } catch (ArrayIndexOutOfBoundsException ex) {
  29.             throw new IllegalArgumentException();
  30.         }
  31.         count = i;
  32.         putIndex = (i == capacity) ? 0 : i;
  33.     } finally {
  34.         lock.unlock();
  35.     }
  36. }

3.2.3 入队列
  1. //入队列，队列已满返回false
  2. public boolean offer(E e) {
  3.     checkNotNull(e); //检查元素是否为空
  4.     final ReentrantLock lock = this.lock;
  5.     lock.lock();//获取锁
  6.     try {
  7.         if (count == items.length) //如果队列已满，返回false
  8.             return false;
  9.         else {
  10.             enqueue(e);//添加元素到队列尾部
  11.             return true;
  12.         }
  13.     } finally {
  14.         lock.unlock();//释放锁
  15.     }
  16. }
  18. //入队列，已满的挂起线程等待
  19. public void put(E e) throws InterruptedException {
  20.     checkNotNull(e);
  21.     final ReentrantLock lock = this.lock;
  22.     lock.lockInterruptibly(); //获取锁，可打断
  23.     try {
  24.         while (count == items.length) //如果队列已满，挂起线程，释放锁
  25.             notFull.await();
  26.         enqueue(e);//入队列
  27.     } finally {
  28.         lock.unlock();//释放锁
  29.     }
  30. }
  32. //入队列，可设置超时
  33. public boolean offer(E e, long timeout, TimeUnit unit)
  34.     throws InterruptedException {
  36.     checkNotNull(e);
  37.     long nanos = unit.toNanos(timeout);//超时时间
  38.     final ReentrantLock lock = this.lock;
  39.     lock.lockInterruptibly();//获取锁，可打断
  40.     try {
  41.         while (count == items.length) {
  42.             if (nanos <= 0)
  43.                 return false;
  44.             nanos = notFull.awaitNanos(nanos);等待超时挂起线程， 释放锁
  45.         }
  46.         enqueue(e);
  47.         return true;
  48.     } finally {
  49.         lock.unlock();
  50.     }
  51. }
  54. //入队列
  55. private void enqueue(E x) {
  56.     // assert lock.getHoldCount() == 1;
  57.     // assert items[putIndex] == null;
  58.     final Object[] items = this.items;
  59.     items[putIndex] = x;
  60.     if (++putIndex == items.length)
  61.         putIndex = 0;
  62.     count++;
  63.     notEmpty.signal(); //唤醒takes线程
  64. }

3.2.4 出队列
  1. //出队列
  2. public E poll() {
  3.     final ReentrantLock lock = this.lock;
  4.     lock.lock();
  5.     try {
  6.         return (count == 0) ? null : dequeue();
  7.     } finally {
  8.         lock.unlock();
  9.     }
  10. }
  12. public E take() throws InterruptedException {
  13.     final ReentrantLock lock = this.lock;
  14.     lock.lockInterruptibly();
  15.     try {
  16.         while (count == 0)
  17.             notEmpty.await(); //队列为空，挂起线程
  18.         return dequeue();
  19.     } finally {
  20.         lock.unlock();
  21.     }
  22. }
  24. //超时出队列
  25. public E poll(long timeout, TimeUnit unit) throws InterruptedException {
  26.     long nanos = unit.toNanos(timeout);
  27.     final ReentrantLock lock = this.lock;
  28.     lock.lockInterruptibly();
  29.     try {
  30.         while (count == 0) {
  31.             if (nanos <= 0)
  32.                 return null;
  33.             nanos = notEmpty.awaitNanos(nanos);//队列为空，超时挂起线程
  34.         }
  35.         return dequeue();
  36.     } finally {
  37.         lock.unlock();
  38.     }
  39. }
  42. //出队列具体逻辑
  43. private E dequeue() {
  44.     // assert lock.getHoldCount() == 1;
  45.     // assert items[takeIndex] != null;
  46.     final Object[] items = this.items;
  47.     @SuppressWarnings("unchecked")
  48.     E x = (E) items[takeIndex];//获取元素
  49.     items[takeIndex] = null; //置空，帮助GC
  50.     if (++takeIndex == items.length)
  51.         takeIndex = 0;
  52.     count--;
  53.     if (itrs != null)
  54.         itrs.elementDequeued(); //通知迭代器更新状态
  55.     notFull.signal();//唤醒put线程
  56.     return x;
  57. }

四、高效读写队列 ConcurrentLinkedQueue(未完成)

ConcurrentLinkedQueue是一个基于链接节点的无界线程安全队列,它采用先进先出的规则对节点进行排序,当我们添加一个元素的时候,它会添加到队列的尾部;当我们获取一个元素时,它会返回队列头部的元素。它采用了“wait-free”算法(即CAS算法)来实现，该算法在Michael&Scott算法上进行了一些修改。
注意:

  • 该队列不支持存储空值

4.1 成员变量

  1. //头节点
  2. private transient volatile Node<E> head;
  3. //尾节点
  4. private transient volatile Node<E> tail;
  6. //节点类
  7. private static class Node<E> {
  8.         volatile E item;
  9.         volatile Node<E> next;
  10.  // Unsafe mechanics
  12.     private static final sun.misc.Unsafe UNSAFE;
  13.     private static final long itemOffset;
  14.     private static final long nextOffset;
  16.     static {
  17.         try {
  18.             UNSAFE = sun.misc.Unsafe.getUnsafe();
  19.             Class<?> k = Node.class;
  20.             itemOffset = UNSAFE.objectFieldOffset
  21.                 (k.getDeclaredField("item"));
  22.             nextOffset = UNSAFE.objectFieldOffset
  23.                 (k.getDeclaredField("next"));
  24.         } catch (Exception e) {
  25.             throw new Error(e);
  26.         }
  27.     }
  28. }

4.2 入队列 无锁实现

  1. public boolean offer(E e) {
  2.         checkNotNull(e);
  3.         final Node<E> newNode = new Node<E>(e);
  5.         for (Node<E> t = tail, p = t;;) {//从尾节点插入
  6.             Node<E> q = p.next;
  7.             if (q == null) { //如果p节点的后继指针为空, 则p为队列的尾节点
  8.                 // p is last node
  9.                 if (p.casNext(null, newNode)) {//把新节点加入队列的尾部
  10.                     // Successful CAS is the linearization point
  11.                     // for e to become an element of this queue,
  12.                     // and for newNode to become "live".
  13.                     if (p != t) // hop two nodes at a time
  14.                         casTail(t, newNode);  // Failure is OK.//设置尾节点
  15.                     return true;
  16.                 }
  17.                 // Lost CAS race to another thread; re-read next
  18.             }
  19.             else if (p == q)
  20.                 // We have fallen off list.  If tail is unchanged, it
  21.                 // will also be off-list, in which case we need to
  22.                 // jump to head, from which all live nodes are always
  23.                 // reachable.  Else the new tail is a better bet.
  24.                 p = (t != (t = tail)) ? t : head;
  25.             else
  26.                 // Check for tail updates after two hops.
  27.                 p = (p != t && t != (t = tail)) ? t : q;
  28.         }
  29.     }

4.3 出队列实现

  1. public E poll() {
  2.     restartFromHead:
  3.     for (;;) {
  4.         for (Node<E> h = head, p = h, q;;) {
  5.             E item = p.item;
  7.             if (item != null && p.casItem(item, null)) {
  8.                 // Successful CAS is the linearization point
  9.                 // for item to be removed from this queue.
  10.                 if (p != h) // hop two nodes at a time
  11.                     updateHead(h, ((q = p.next) != null) ? q : p);
  12.                 return item;
  13.             }
  14.             else if ((q = p.next) == null) {
  15.                 updateHead(h, p);
  16.                 return null;
  17.             }
  18.             else if (p == q)
  19.                 continue restartFromHead;
  20.             else
  21.                 p = q;
  22.         }
  23.     }
  24. }

五、随机数据结构：跳表(SkipList)

5.1 跳跃表了解

跳跃表（skiplist）是一种随机化的数据结构， 在 1989 年由 William Pugh 在论文《Skip lists: a probabilistic alternative to balanced trees》中提出， 跳跃表以有序的方式在层次化的链表中保存元素，搜索、插入和删除的时间复杂度为O(logN)

  • 图示(WiKi)


5.2 Java 实现简单的SkipList

  • 定义SkipList 的节点 ```java /**
  • 节点类 */ class Node { //数据域 int key; //forward 数组，用于保存不同层级的指针 Node[] forwards; //节点最大等级 int maxLevel = MAX_LEVEL; } ```
  • 使用随机数算法决定新增节点的高度 ```java /**
  • 定义最大层级 / private final static int MAX_LEVEL = 16; /*
  • 随机选择节点作为索引的概率, 这里取50% / private final static float P = 0.5f; /*
  • 随机等级算法 *
  • @return 返回随机层数 */ private int randomLevel() { int level = 1; while (Math.random() < P && level < MAX_LEVEL) {
    1.   level++;
    } return level; } ```
  • 跳表的插入实现

基本思路：我们将会从跳表的最高等级开始比较当前节点(一般会定义一个头节点)的下一个节点的key 与将要插入的key

  1. 如果下一个节点的key 小于将要插入节点的key，继续在同一层等级中遍历下一个节点
  2. 如果下一个节点的key 大于将要插入节点的key， 保存当前节点i 到数组update[i] 中，向下移一个等级继续遍历
  • 插入图示（WIKI）


  • Java 代码实现

5.3 并发容器 ConcurrentSkipListMap

参考
