资料
应用
参考文章

资料

基础登录
https://xui.ptlogin2.qq.com/ : 登录的说明
https://xui.ptlogin2.qq.com/assistant/troubleshooter.html : 这个网址是登录助手的地址
通过王者营地抓取王者数据 - 图1
QQLogo
https://q.qlogo.cn/headimg_dl?dst_uin=1057538126&spec=640
https://q.qlogo.cn/headimg_dl?dst_uin={qq}&spec=640

应用

获取第一凭证

入口

通过此入口进行自动登录

王者营地

https://xui.ptlogin2.qq.com/cgi-bin/xlogin?appid=716027609&pt_3rd_aid=1105200115&daid=381&pt_skey_valid=0&style=35&s_url=http%3A%2F%2Fconnect.qq.com&refer_cgi=m_authorize&ucheck=1&fall_to_wv=1&status_os=11&redirect_uri=auth%3A%2F%2Ftauth.qq.com%2F&client_id=1105200115&response_type=token&scope=all&sdkp=i&sdkv=3.5.3_full&status_machine=HUAWEI2300P&switch=1&h5sig=&loginty=1

和平营地

https://xui.ptlogin2.qq.com/cgi-bin/xlogin?appid=716027609&pt_3rd_aid=1105412664&daid=381&pt_skey_valid=0&style=35&s_url=http%3A%2F%2Fconnect.qq.com&refer_cgi=m_authorize&ucheck=1&fall_to_wv=1&status_os=11&redirect_uri=auth%3A%2F%2Ftauth.qq.com%2F&client_id=1105412664&response_type=token&scope=all&sdkp=i&sdkv=3.5.3_full&status_machine=HUAWEI2300P&switch=1&h5sig=&loginty=1
登录成功的代理页面

登录成功跳转到此页面, 获取授权数据, 这里的授权数据用来获取第二凭证

https://imgcache.qq.com/open/connect/widget/mobile/login/proxy.htm?#&t=1634113064#&openid=B75CBDC928XXXXXXXXXXE78B4F793202&appid=1105200115&access_token=C95353EF3ABFBDA12A48D607AFCE9ADA&pay_token=DD03F57240A45EB2FDB1549026A58D6D&key=d5575f4f1055d0fb1968689b242f60a2&serial=&token_key=&browser=0&browser_error=0&status_os=11&sdkv=3.5.3_full&status_machine=HUAWEI2300P&update_auth=0&has_auth=1&auth_time=1634113041450&page_type=1&redirect_uri_key=713A4A803423112ECEEDE657A39910ED30A602D2E8F0417E88C213FFEE9E7E364329E571D17C047F7404C14A174AAF074FBFB35FF64D5A6C8E5161343D0ED0ADEC147206D34B3A62C8274F63AE34D9B23F2D168CAE3B7D564BFFA9EE94AF53211EC9AC5EAFFECF7CD2AF327544CA7F08140EE9483A48EDC71511B57AEA97C267759C8300F7083C2E4E72474AF7C61A2A1CFFAC7E79440C7290A17C0BC3AC4D6F4EF1E27E4D00E4CBE0F6E961302207CC716B2E4F16AB2339951C9FDD0E5AAA5FB26D5EA90B67EB70BB69ECFF681850C440CC0E903A42DB19C042A66ED31F0A512CF512A3BD8A0AC1963BE5524E8A8ED60589BD0F5A6ECB510DB9185453DE3AFCDF0D10AABE950A7E468EF1E5D41C49DBF9A8FA546ED1037E91D90D6306BC15A8E95682E5B90536FBF0962CCED66EC6D2
params: 参数

openid : B75CBDC928XXXXXXXXXXE78B4F793202
appid  : 1105200115
access_token : C95353EF3ABFBDA12A48D607AFCE9ADA

王者营地登录, 获取第二凭证

通过三方登陆信息进行登录, 这里使用 MAC 的 charles 进行抓包得到, 细节不细说

Url : https://ssl.kohsocialapp.qq.com:10001/user/login
这里发送的数据包含两部分
一部分是 Header, 另一部分是 Post 参数, 可以通过邮件 charles 复制 curl request 来获取到这个数据并进行解析, 以下所有的接口请求均和此接口类似
Post 数据

accessToken    C95353EF3ABFBDA12A48D607AFCE9ADA
avatar    http://thirdqq.qlogo.cn/g?b=oidb&k=RxwhyCoLHqztjjNt6xMISQ&s=40&t=1556321295
cChannelId    0
cClientVersionCode    57110121091573
cClientVersionName    5.71.101
cCurrentGameId    20001
cGameId    20001
cGzip    1
cRand    1634174723965
cSystem    ios
cSystemVersionCode    14.6
cSystemVersionName    iOS
delOldUser    0
gameAreaId    0
gameId    20001
gameOpenId
gameRoleId
gameServerId    0
gameUserSex    0
isTestFlight    0
key1    c8f9b1fb-3c27-444d-a728-95dba7a1ddd4
key10    3948838912
key11    ARM64
key13    WiFi
key14
key15    00000000-0000-0000-0000-000000000000
key18    iPhone11,6
key19    0.000000
key20    0.000000
key21
key22
key6    414
key7    896
key9    iPhone
loginType    openSdk
nickname    多厘
openId    B75CBDC928XXXXXXXXXXE78B4F793202
reportHashValue    10756235328
sex    1
userId    0

返回数据

{
    "result": 0,
    "returnCode": 0,
    "returnMsg": "",
    "time": "175.9",
    "data": {
        "uin": "B75CBDC928XXXXXXXXXXE78B4F793202",
        "userId": "1842163274",
        "token": "JRNKfH8B",
        "new": false,
        "userSig": "eJxlkF1PwjAUhu-3K5pdG9fTraOQeDFkUaKFqEXXXXXXXXX7j0dZkL3qBfqJH6qIq8W42BAsAQX6db39YPJ71cTg__",
        "needAllUin": true,
        "time": 1634174724,
        "sex": 1,
        "avatar": "http://thirdqq.qlogo.cn/qqapp/1105200115/B75CBDC928XXXXXXXXXXE78B4F793202/100",
        "platformAvatar": "http://thirdqq.qlogo.cn/qqapp/1105200115/B75CBDC928XXXXXXXXXXE78B4F793202/100",
        "userName": "\u591a\u5398",
        "userPhone": "152****9156",
        "dCode": "",
        "unbind": [],
        "forceChangeName": 0,
        "forceBindPhone": 0,
        "bigAvatar": "http://thirdqq.qlogo.cn/qqapp/1105200115/B75CBDC928XXXXXXXXXXE78B4F793202/160",
        "snsnickname": "\u591a\u5398",
        "guideInfo": [...],
        "youthPrivacyStatus": {
            "isAdult": 0,
            "mode": 0,
            "layer": 0
        }
    }
}

获取信息接口

获取用户信息(openmobile)

这里用于后续用户的登录或者是没有用户的营地注册

https://openmobile.qq.com/user/get_simple_userinfo?format=json&status_version=14&openid=B75CBDC928XXXXXXXXXXE78B4F793202&status_machine=iPhone11%2C6&oauth_consumer_key=1105200115&status_os=14.6&sdkv=3.3.6_lite&access_token=C95353EF3ABFBDA12A48D607AFCE9ADA&sdkp=i

{
    "ret": 0,
    "msg": "",
    "is_lost": 0,
    "nickname": "多厘",
    "gender": "男",
    "gender_type": 1,
    "province": "山东",
    "city": "济南",
    "year": "1986",
    "constellation": "",
    "figureurl": "http:\/\/qzapp.qlogo.cn\/qzapp\/1105200115\/B75CBDC928XXXXXXXXXXE78B4F793202\/30",
    "figureurl_1": "http:\/\/qzapp.qlogo.cn\/qzapp\/1105200115\/B75CBDC928XXXXXXXXXXE78B4F793202\/50",
    "figureurl_2": "http:\/\/qzapp.qlogo.cn\/qzapp\/1105200115\/B75CBDC928XXXXXXXXXXE78B4F793202\/100",
    "figureurl_qq_1": "http://thirdqq.qlogo.cn/g?b=oidb&k=RxwhyCoLHqztjjNt6xMISQ&s=40&t=1556321295",
    "figureurl_qq_2": "http://thirdqq.qlogo.cn/g?b=oidb&k=RxwhyCoLHqztjjNt6xMISQ&s=100&t=1556321295",
    "figureurl_qq": "http://thirdqq.qlogo.cn/g?b=oidb&k=RxwhyCoLHqztjjNt6xMISQ&s=640&t=1556321295",
    "figureurl_type": "1",
    "is_yellow_vip": "0",
    "vip": "0",
    "yellow_vip_level": "0",
    "level": "0",
    "is_yellow_year_vip": "0"
}

获取用户信息(营地)
Url : https://ssl.kohsocialapp.qq.com:10001/user/getuserinfo
这里通过第二授权的 token / openid 来获取用户的详细信息
Resp

{
    "result": 0,
    "returnCode": 0,
    "returnMsg": "",
    "time": "36.4",
    "data": {
        "nickname": "\u591a\u5398",
        "sex": 1,
        "avatar": "http:\/\/thirdqq.qlogo.cn\/qqapp\/1105200115\/B75CBDC928XXXXXXXXXXE78B4F793202\/100",
        "userLevel": 3,
        "userId": 1842163274
        ...
    }
}

获取游戏信息(营地)
Url : https://ssl.kohsocialapp.qq.com:10001/game/setting

同样使用 Header / Form

Resp(信息太多)

{
    "result": 0,
    "returnCode": 0,
    "returnMsg": "",
    "time": "44.9",
    "data": {
        "games": [
            {
                "name": "\u738b\u8005\u8363\u8000",
                "id": 20001,
                "icon": "http://yoyo.qq.com/icon/20160317113804.png",
                "icon2": "http://yoyo.qq.com/icon/20160615123216.jpg",
                "icon3": "",
                "chat": true,
                "role": true,
                "menu": true,
                "background": "http://yoyo.qq.com/background/20160317122846.jpg",
                "param": "{\"commentDomain\":\"sgame.coral.qq.com\",\"friendReq\":1,\"openMoment\":1,\"changeRole\":1}",
                "chatText": "",
                "shortDesc": "123232323",
                "menuInfo": [{}, {}],
                "sideInfo": [],
                "sHotKey": {
                    "prefix": "",
                    "hotkey": "\u59b2\u5df1\u79d2\u6740\u76ae\u80a4"
                }
            }
        ],
        "maxUinCount": 5
        // ...
    }
}

获取 Uin(营地)
Url : https://ssl.kohsocialapp.qq.com:10001/user/alluin

可能获取游戏的 OpenID

{
    "result": 0,
    "returnCode": 0,
    "returnMsg": "",
    "time": "6.6",
    "data": [{
        "gameId": 20001,
        "uin": "B75CBDC928XXXXXXXXXXE78B4F793202",
        "isMainUin": true,
        "icon": "http:\/\/thirdqq.qlogo.cn\/qqapp\/1105200115\/B75CBDC928XXXXXXXXXXE78B4F793202\/100",
        "nickname": null
    }]
}

获取角色(Roles)
可能有关联的数据 : gameOpenId 和用户角色相关
Url : https://ssl.kohsocialapp.qq.com:10001/game/chatroles
Resp

{
    "result": 0,
    "returnCode": 0,
    "returnMsg": "",
    "time": "44.2",
    "data": {
        "roles": [
            {
                "uin": "B75CBDC928XXXXXXXXXXE78B4F793202",
                "isMainUin": true,
                "icon": "http://thirdqq.qlogo.cn/qqapp/1105200115/B75CBDC928XXXXXXXXXXE78B4F793202/100",
                "nickname": null,
                "gameId": "20001",
                "areaId": "1",
                "serverId": "1126",
                "roleId": "1124906535",
                "isMainRole": false,
                "add": 1,
                "common": 1,
                "vest": 0,
                "display": 1,
                "roleName": "多厘",
                "roleIcon": "http://q.qlogo.cn/qqapp/1104466820/9A2B0735B2620F0B52BC8962B433AEC6/100",
                "level": 6,
                "status": 1,
                "originalRoleId": "1843092194",
                "roleJob": "倔强青铜III",
                "openid": "9A2B0735B2620F0B52BC8962B433AEC6",
                "receive": 1,
                "onlineTime": 1634180314,
                "f": 1,
                "roleJobId": 1,
                "roleDesc": "手Q其他 青铜III",
                "battleGroupId": "",
                "areaName": "其他",
                "serverStatus": 3,
                "serverName": "手Q116区",
                "roleText": [
                    "其他手Q116区",
                    "倔强青铜III",
                    "Lv.6"
                ],
                "groupIds": [],
                "disLimit": [...],
                "menu": []
            }
        ],
        "groups": [],
        "showWX": false
    }
}

获取英雄皮肤
Url : https://ssl.kohsocialapp.qq.com:10001/play/h5getheroskinlist
获取英雄列表
Url : https://ssl.kohsocialapp.qq.com:10001/play/h5getherolist

通过营地 ID 获取到用户详细

营地 ID : 1874910711
流程和抓取数据一样, 找到用户的角色信息, 代入并获取用户的详细信息

参考文章

https://www.cnblogs.com/qiyeboy/p/9496262.html
https://cloud.tencent.com/developer/article/1351344
http://huazai.eleuu.com/?post=7
https://q.cnblogs.com/q/105900/
https://pibigstar.github.io/2019/09/22/QQ快速登录协议分析/
https://www.jianshu.com/p/03517d07ad84
https://www.iculture.cc/sg/pig=1267
